Milling and engraving CNC machines allow to realize any of your ideas. All you need is to prepare a model / vector in the program and submit the job to the machine , the rest themselves .
AMAN 6040 4axis1.5KW Z + - is a professional machine with table size 600 x 400 mm, is a modification of 6040 4axis 1.5KW.
The main distinguishing feature of the base model 6040 4axis 1.5KW - extended adjustment range on the axis Z. This allows full use of the rotator ( milled products of large diameter ) , as well as sharpen deep reliefs and make processing requiring margin axis Z.
As a basic model , has the most powerful ruler in the spindle and AMAN full four axes : XYZ + A- rotator . The spindle has a water cooling - it provides reliability and long service life.
The machine can easily be placed in a small workshop or home. Will apply for relief 3d- treatment ( three-dimensional objects , reliefs, souvenirs, cliche ) , engraving (personalization items , creating labels , jewelry , engraving PCBs ) , all types of cutting (letters and labels , signs , models ) , drilling .
The main types of treatment :
- etching
- cutting
- 3d- milling
- boring
- milling and engraving on a rotating axis.
Allows you to handle :
- Wood
- plastic
- orsteklo
- Chipboard, MDF , plywood
- soft metals (copper, aluminum , brass)
Main areas of application :
- advertising industry
- creative workshops
- jewelry / designer items
- merchandise
- interior and decor elements
To control the machine will need a computer with LPT-port /usb port and the operating system Windows XP/windows 7
technical characteristics
Working field size 600 x 400 x 80 mm (depth adjustable)
4 axles (XYZ + A-steering axle)
Spindle power, W / Collet 800W, water-cooled, ER11
Resolution, 0.0125 mm
Maximum speed (work / feed, mm / min) 2000/3000
Spindle speed (rev / min) to 24000
Management system Mach3 interface, Windows 2000/XP/7
Compatible software MACH3, ARTCAM, TYPE 3, UCANCAM, KCAM etc.
Power supply 220V ± 10% 50HZ
Dimensions (mm) / Weight (kg) 520x600x530/60
|
|
